Travelling Head 25 Ton Hydraulic Cutting Machine Die Cut Leather Foam Plastic

This is a used THNC-2570 Die Cutting Machine with Travelling Head in great running condition!

THNC Cutting Machine with Travelling Head for die-cutting of sheet material

Model: THNC-2570

The Travelling Head Press is used for cutting textiles, plastics, foam, gaskets, rubber, and other materials.

• Efficient cuts of single or multiple layers of material
• Uses a hydraulic-down and hydraulic-up system to provide an even cutting depth
• Very quiet
• Special cutting pad locking device can prevent cutting pad from warping
• High speed
• Heavy-duty construction
• Die height and material height can be set quickly

Cutting Force 28 Tons (25 Metric Tons)

Cutting Head 25.6” x 25.6” (650 x 650 mm)

Cutting Stroke 5.9” (150 mm)

Maximum Daylight 7.1” (180 mm) (without pad)

Machine Bed 25.6” D x 70.9” W (650 x 1800 mm)

Main Motor 3 HP

Gross Weight 4,300 lbs. (1951kg)

Series TH - 25 Tons

Range of application

- Die cutting application of any material such as hard-board , paper , textiles , plastics , sponge ,    leather , rubber , packing , floor covering , carpeting , glass-fiber cloth , cork, labels , envelopes , paper tubes , garments , gaskets , plastic novelties , rubber products ,  shoes , leather goods , toys etc.

Advantages...

- 10mm slow speed of cutting head before touching the cutting die (Material not included) to minimize the size difference between top layer and lowest layer material. The function bring working capacity of one set equal to 2 sets other brand due to double layer per cutting stroke. It also bring top durability of cutting pad and cutting dies.

- With good quality hydraulic oil , hydraulic cylinder with U-Packing and special wear rod can ensure no oil leakage.

- Two hand operation for safety.

PTWS # LRBG-000000-012822B

R111823

Picture# 012822

Bid with Confidence on this item, check our feedback!!!

* All information deemed accurate but may vary from model to model.

Contact Larry for any questions you may have...

Contact us at Four Zero One - Nine Six Five - Five Five Five Seven or Contact us through ebay
